Description
| Specifications | |
| Tunnel Size | W655mm × H505mm |
| Speed | 0.20m/s |
| Hight of Transmission Belt | 700mm |
| Maximum Load | ≤180Kg(Adequate distribution) |
| Wire Resolution | 40 AWG(0.0787mm metal wire) |
| Space Defintion | HorizontalΦ1.0mm/VerticalΦ2.0mm |
| Penetrate Definition | 34 AWG |
| Penetration | 38mm Steel board |
| Monitor | 21.5 inch LED |
| System Function | High density alarm, Explosive/Drug auxiliary detect, TIP, Luggage counter, System running timer, X-ray emitting timer, Training, 64 times continuous zoom in |
| Film Safety | ASA/ISO1600 standard of film safety |
| X-ray System | |
| Tube Voltage | 150kV |
| Cooling | Seal oil cooling/100% |
| Single Inspection Dosage Rate | ≤1.0μGy |
| Radiation Leak Dosage | 0.1 μ Gy/h (5cm from the surface) |
| Installation Specification | |
| Package Size | L2240mm × W1170mm × H1755mm |
| Console Desk Size | L805mm × W900mm × H1320mm |
| Package Weight | 680KG+105KG(Console desk) |
| Power Consumption | 1kVA |
| Noise | 53.8dB(A) |
